PATENT PENDING

BASIC SET INCLUDES:

• S20R-100 light head
• Ballast
• Heavy "Art Cloth" diffuser
• 40 degree eggcrate grid
• 3m head cable
• 7m head cable
• 3m mains cable
• V-clamp stand mount
• Extension rod
• Light stand mount
• Tube style transport bag

S20R-100 Studio Light

The CineVeam Studio S20R-100 delivers refined, flattering soft light in a compact 2' circular format designed for studio, broadcast, and commercial production. Combining bi-color output with integrated DMX and CRMX control, it provides the polished quality of a beauty light while remaining small enough for precise placement in tighter environments.

The 2' round shape creates controlled, intimate softness that is especially effective for close portrait lighting, beauty work, interviews, and accent applications. Its circular geometry produces smooth facial illumination and a clean, natural round catchlight that adds dimension without flattening the subject.

Smaller and more focused than larger round fixtures, the S20R-100 is ideal when a broad soft source would be difficult to position or too overwhelming for the scene. It works equally well as a compact portrait key, an overhead beauty light, or a subtle edge light that adds shape while preserving contrast and separation.

With LEDs integrated directly into the fabric body, the entire surface emits evenly across the fixture, eliminating internal hotspots and maintaining consistent color and output across the full dimming range.

Umbrella-style Quick Deployment System

The CineVeam quick-deploy system opens in seconds using a central pull-and-lock rod built directly into the fixture. Simply hold the center locking collar and pull the rear deployment rod to open the light, just like an umbrella in reverse. Once locked, the exposed 5/8" rear rod provides approximately 14" of built-in mounting length for grip heads, clamps and rigging.

For tighter overhead or studio setups, the rear rod can be removed at the threaded joint located 7 cm behind the locking collar. That built-in 7 cm section is designed to fit directly into a grip head or the included stand adapter, reducing the overall depth of the fixture while maintaining safe mounting.

The removable rear section may also be replaced with an optional 1 m extension rod for boom mounting or greater stand clearance. Both ends include captive safety pins, and the rear end cap incorporates a hanging loop for storage and safety cable attachment.

[TABS]

KEY FEATURES

• Compact 2' circular soft light format for portrait, beauty, and interview lighting
• Bi-color output adjustable from 2700K to 6500K
• Integrated DMX and built-in CRMX for professional wired and wireless control
• Creates clean, natural round catchlights and flattering facial illumination
• Ideal as a compact portrait key, overhead beauty light, accent light, or edge light
• Provides more controlled, intimate softness than larger round fixtures
• Fast setup design deploys in approximately 3 seconds
• CRI 96+ and TLCI 96+ for accurate skin tones and broadcast-quality color reproduction
• Passive cooling in the light head allows silent operation in sound-sensitive environments
• IP-rated ballast provides reliable performance for studio and location production
• Ultra fast umbrella-style pull-and-lock deploys in approximately 3 seconds using the integrated central 5/8" rod system
• Built-in 5/8" rear mounting rod provides approximately 14" of grip-ready mounting length and can be removed at the threaded joint for tighter overhead spaces
• Removable rear rod section may be replaced with an optional 1 m extension rod for additional boom reach or stand clearance
• Captive safety pins and integrated hanging loop provide secure transport, storage and safety cable management

SPECIFICATIONS

APPLICATIONS

The S20R-100 is designed for studio lighting, interview lighting, beauty work, livestream production, broadcast applications, and commercial content where a compact but refined soft light is required.

Its 2' round size makes it especially useful in smaller studios, tight sets, and overhead positions where larger fixtures would be difficult to place. It excels for close portrait lighting, tabletop shoots, makeup work, and as a controlled accent or rim light that preserves depth and contrast.

CONTROL & POWER

The S20R-100 supports Bluetooth app control, integrated DMX, and built-in CRMX wireless operation, making it equally practical for small location setups or fully integrated studio lighting systems. Brightness can be adjusted from 0.1% to 100%, with precise bi-color control from 2700K to 6500K.

Integrated DMX allows direct control from lighting consoles, while CRMX enables reliable wireless operation without additional receivers. Bluetooth app control is available for quick adjustment when working alone or on smaller productions.

The ballast can operate from AC mains power or dual 14.8V batteries, allowing the fixture to move easily between studio and location work. The light head uses silent passive cooling for completely noise-free operation, while the ballast employs a low-noise fan to ensure stable performance.

Available 3 m and 7 m head cables may be coupled together to extend overall cable length. Cable runs up to 14 m are supported; expect approximately ±8% reduction in output at maximum length. Longer runs are not recommended.

ACCESSORIES

• Additional 1/4 and Art Cloth diffusers available
• 20° eggcrate
• Replacement fabric grids
• Extension rod
• Pro style carrying case
